proFRAME Base Board 3.1 PXIe
Making its debut at embedded world, the proFRAME Base Board 3.1 PXIe is the latest member of the proFRAME product family of modular video grabber and playback systems, offering support for most automotive, industrial and medical cameras and displays.
The robust 3U module uses the PXI Express Gen 3 x8 bus and brings proFRAME’s wide range of supported interfaces (GMSL, FPD-Link, GVIF3, ASA Motion Link and more) to PXIe-based systems. It is designed for use in measuring and automation systems deployed in production and machine supervision or industrial testing applications in the aerospace, automotive and railway fields. A typical application is the automated testing of automotive cameras, supporting a wide array of cameras, displays, and ECUs.
Just like earlier PCIe and CompactPCI Serial base boards, the new PXIe module realizes support for a variety of transmission standards through two slots for easily swappable proFRAME interface adapters, with each base board supporting up to eight video streams.
To speed up adoption of the proFRAME system into existing PXIe-based testing systems, Solectrix offers configuration files for a multitude of cameras from launch and supports integration into National Instruments’ LabVIEW platform.
Vision Prototyping as a Service – with SXIVE 3.0
The latest installment of the Rapid Imaging Prototyping System SXIVE aims to bridge the gap between prototype and target, particularly by simplifying implementation of the modeled system on SoC platforms, which often come with their own black box ISP. While SXIVE 2.0 is uniquely suited to testing a wide range of sensors and algorithms in pre-development phase, often shortening the time to an initial image to a week or two, the system has so far been primarily aimed at eventual ISP implementation on FPGAs.
Answering customer calls for more support with implementation on SoCs, the new SXIVE 3.0 is built around the idea of “Vision Prototyping as a Service”. It introduces an intermediate format that abstracts and encapsulates the ISP configuration developed in the GPU-based prototyping environment, making it transferable to manufacturer-specific SoC ISPs. Fine-tuning of the overall ISP chain thus focuses on aligning this configuration with the behavior and constraints of the SoC’s integrated, largely opaque ISP blocks, identifying deviations early and compensating for them through targeted adjustments and complementary pre-processing steps.
By dealing with such issues within the dedicated target architecture on a PC-based platform before the final implementation on an embedded system, SXIVE 3.0 makes a large swath of debugging options and tools available at a crucial point in the project’s development. This approach ultimately ensures that the final image is extremely close to the results achieved with the prototyping configuration, thus immensely shortening implementation time on the series production target platform and lowering development costs.
The SXIVE 3.0 software package retains all features of the previous iterations, including the SXIVE SoftISP SDK, the SXIVE Calibration SDK, the SXIVE Sensor Configuration Tool, and advanced image quality analysis courtesy of the powerful iQ-Analyzer-X from Image Engineering. Target markets include robotics and automotive projects by tier ones utilizing, e.g., ARM-based SoCs.
SXVPU – Smart eXtensible Vision Processing Unit
SXVPU is an AI-powered imaging platform designed to tackle challenges like object recognition and machine learning integration through its efficient real-time processing of high-resolution video streams up to 4K.
The new SXVPU model boasts a metal housing with IP67 protection, making it ideal for the harsh environments typically associated with its targeted use in industrial and agricultural vehicles.
With its specialized AMD-based hardware architecture and support for multiple cameras and sensors, SXVPU is set up to use impeccable image data straight from the sensor for processing by neural networks or conventional algorithms before encoding the data for transmission via Ethernet.
The result is a perfect solution for viewing and vision applications in mobile automation.
sinaSCOPE Digital 3D Microscopy Systems
Following last summer’s sinaSCOPE product family overhaul with new sinaSCOPE Basic, Complete and Upgrade models, Solectrix is adding even more configuration options to its sinaSCOPE range:
The new sinaSCOPE OEM Platform is a complete integration kit that allows customers to implement sinaSCOPE digital 3D microscopy technology in their medical device, with Solectrix supporting customization according to the customer’s requirements.
A new 27-inch 3D display with fast response times joins the regular 15.6-inch model in Q1/2026.
For sinaSCOPE Basic and Complete models, new 100-mm high-magnification lenses raise the maximum zoom level to 23× (without digital zoom) on the standard 15.6-inch monitor and 34× on a 27-inch model. Available Q1/2026 – and existing systems can be retrofitted to support the new option.
A new focus control module for sinaSCOPE Complete and Complete Pro systems electrically adjusts image focus and allows storing and recalling predefined object distances. Available Q2/2026, including retrofit options.
VIORYTI® GATE AX2
VIORYTI® GATE AX2 by AST-X, is a multi-connective LPWAN IoT Gateway with LTE / 4G designed for industrial and large-scale IoT deployments.
Supporting both mioty® and LoRa® in a single device, it enables reliable long-range communication of up to 5 km in urban and 15 km in open environments. With capacity for up to 50,000 devices, integrated LTE backhaul, and an IP65-rated aluminum housing, the gateway is built for robust outdoor and industrial operation.
A multi-layer security architecture including Secure Boot, hardware-based security elements, encryption, tamper detection, and remote updates ensures high data integrity and infrastructure protection. VIORYTI® GATE AX2 forms a secure and scalable backbone for modern industrial and smart infrastructure applications.
Solectrix can be found at embedded world 2026 from March 10 to 12 in hall 4A, booth 152.
Solectrix considers itself an innovative, independent full-service provider in the field of embedded electronics. The company develops electronic components and software, but also complete devices and systems – conforming to standards, efficiently and individually. This way we create high-quality customer-specific solutions and off-the-shelf products that excel through the harmonic interplay of functional hardware, perfectly matched firmware and modular software. Solectrix supports its customers across the entire product lifecycle: From consulting and conception, product or system development, production and certification to lifecycle management and support. In 2008, solectrix systems GmbH was launched as a production and sales company for customer-specific systems and devices built to the highest quality standards. In 2024, solectrix GmbH and solectrix systems GmbH joined forces with ASSDEV GmbH and AST-X GmbH.
With about 250 motivated employees, company buildings in Fürth and Forchheim, and field offices in Mannheim and Leipzig, the companies provide a wide array of services across many markets, from electronics design and development to full-scale manufacturing. The companies now operate under the holding brand AXSELION Group. AXSELION Group stands for a common framework within which all four partner companies continue to operate independently with no changes to their usual responsibilities, points of contact, or processes.
